Cleaning Menu
ORCA Sonar System
24
Cleaning
Sub-Menu Description Options
Intvl
Keeps the actuator swing extended for the selected time interval before
retracting to normal position
6 minutes
3 minutes
1 minutes
Spry
Uses Relay 3 to activate an external system (such as a spray cleaner) for the
selected time. The actuator swing will be at full extension for this selected time.
90 seconds
60 seconds
30 seconds
Solenoid Uses Relay 3 to drive an external solenoid (used for pneumatic actuator control) Selectable
Brush Uses Relay 3 to drive an external solenoid (used for wiper brush control) Selectable
Actuator
Selects Actuator auto cleaning function (default cleaning option). Actuator will
extend and retract based on programmed timer.
See 'Actuator'
Off Disables Cleaner function Selectable
Actua In Manually trigger Actuator to 'in' (home) position* Selectable
Actua Out Manually trigger Actuator to 'out' (extended) position* Selectable
Actuator
Sub-Menu Description Options
Act Max
Act Min
Adjust the default swing position (Max) and Home position (Min Adjuatable (mm)
Cycle Set timer in minutes between Actuator swings Adjustable
VoltCutOff
Set minimum voltage present before Actuator action is cancelled and error
message ActuatorErr or ActuatorVsErr is displayed on screen
Default 14V
*If testing with these parameters you must follow this sequence for the Actuator to function correctly
• Select 'Actua Out'
• Select 'Actua In'
• Select 'Actuator'
The Actuator must be returned to 'In' mode before activating the auto cleaning function for standard operation.
