Setup Procedure
ORCA Sonar System
22
Output Adjustment
The Output Adj menu contains parameters related to adjusting analogue, switch & communication protocol relayed
settings.
Parameter Description Options
FillDamp
EmtyDamp
Adjust first output response time /
smoothness
Value in pulses, approximately 2 pulse per second
4mA Adj Fine tune the 4mA output current Adjustable
20mA Adj Fine tune the 20mA output current Adjustable
Analog Invert analogue from 4-20mA to 20-4mA 4-20mA 20-4mA
Simulate
A simulated distance reading is transmitted
as analogue (distance measured from sensor
face)
Adjustable
4mA Adj2 Fine tune the 4mA output2 current Adjustable
20mA Adj2 Fine tune the 20mA output2 current Adjustable
Comm Type
• Adjust communication protocol settings
• Analogue and Switch models include
Modbus as standard
See 'Comms Type' section
RlyMod 1-3 Configure Relay actions See 'Relay Actions' section
Cleaning Set auto cleaner parameters See 'Cleaning' section
Bk Light Turn on/off LCD backlight On/Off
DispChar
Switch display from 12 character to 8
character (older units)
12 digit / 8 digit
V In Chk
When active the unit will switch to failsafe
mode if input voltage drops below required
power. When not active unit will display ‘Input
Voltage too low' on the display.
On / Off
