HBC-Radiomatic technos A - Technical Data Overview; Dimensions and Diagram

32 / 34
Technical Data
Max. number of control commands
-
Unique system addresses
Over 1.000.000 combinations
Supply voltage
3.7 V
Safety function
E-STOP:
Performance Level d, category 3 according to EN
ISO 13849-1:2015
Frequency ranges
405 – 475 MHz
1
, 865 – 870 MHz,
902
– 928 MHz, 1210 – 1258 MHz
1
2.4 GHz: 2402
– 2480 MHz
DECT: 1790 – 1930 MHz
Channel spacing
12,5 / 20 / 25 / 50 / 250 kHz
2.4 GHz: 1 MHz
DECT: 1,728 MHz
Antenna
Internal
Battery type
BA405_ _ _ (Li-ion)
Battery capacity
6 Ah
Continuous operating time
Approx. 20 h
Operating temperature range
-20 °C … +70 °C (-4 °F ... +158 °F)
Housing material
Glass-fiber reinforced plastic / PA6 GF30
Dimensions
255 x 162 x 169 mm (10.04 x 6.38 x 6.65 inches)
Weight (incl. battery)
Approx. 1.8 kg (4.0 lbs.)
Protection class
IP65
1
Not all frequency ranges available.
Dimensions
