20
PME-MP55
HBM A0563-5.5 en
4.5 Synchronisation
Synchronisation is advisable when
D the transducer cables are connected in parallel to several devices
D unshielded channels lie close together
Synchronisation prevents carrier-frequency differences giving rise to beat in-
terference.
123456
ON
S10
123456
ON
Master
Slave
S10
S10
Fig. 4.8: Setting up master/slave
To synchronise several instruments, set up one of them as Master. Set up all
the other instruments as Slaves.
Synchronisation between modules should always be carried out via the ribbon
cable- even when you are not working with CAN-bus.
