8 Error messages/operating status (LED)
Depending on the display mode, different error messages may be displayed in
place of the measured value:
HrdwOvfl ADC+Ovf Grs+Ovfl Scal.Err
ADC-Ovf Grs-Ovfl UrCalErr
Signal status (mode)
Gross
- - - - - - -
Possible error message
Net
- - - - - - -
! >T<
Input signal
- - - - - - -
!
mV/V
HrdwOvfl ADC+Ovf Net+Ovfl Scal.Err
ADC-Ovf Net-Ovfl UrCalErr
HrdwOvfl ADC+Ovf UrCalErr
ADC-Ovf
Analogue output signal
- - - - - - -
!
V
HrdwOvfl ADC+Ovf AnlgOvfl
ADC-Ovf AScalErr UrCalErr
Max. peak value signal
- - - - - - -
!
PkMaxOvf UrCalErr
Min. peak value signal
- - - - - - -
!
PkMinOvf UrCalErr
Peak/peak signal
- - - - - - -
!
PkPk Ovf UrCalErr
!
When enabled
