44
PME-MP55
HBM A0563-5.6 en
7.5 Object directory: manufacturer-specific objects
Parameters that refer to measured values are scaled as long-coded (32-bit in-
teger) with figures in the appropriate range. The position of the decimal point
is defined in object 2120Hex. Alternatively these quantities are also available
as floating values (IEEE754-1985 32-bit format) (see page 53).
Index
(hex)
Sub-
index
Name Format Attr. Values
Measured values:
2000 1 Gross measured value integer32 ro
2001 1 Net measured value integer32 ro
2002 1 maximum integer32 ro
2003 1 minimum integer32 ro
2004 1 Peak-to-peak integer32 ro
2005 1 Measured value in
mV/V
integer32 ro 5 Decimal places
2006 1 Analogue output value
V
integer32 ro 3 Decimal places
2010 1 Measured value status unsigned8 ro Bit 0: Meas.val. overflow
Bit 1: Analogue out. overfl.
Bit 2: Scaling defective
Bit 3: EEPROM error
Bit 4..7: Limit switch 1...4
2011 1 Measured value
status_2
unsigned32 ro Bit 0: Overfl. hardware
Bit 1: Overfl. ADC
Bit 2: Overfl. gross
Bit 3: Overfl. net
Bit 4: Overfl. anal. outp.
Bit 5: Overfl. maximum
Bit 6: Overfl. minimum
Bit 7: Negative overfl.
Bit 8: Limit value 1
Bit 9: Limit value 2
Bit 10: Limit value 3
Bit 11: Limit value 4
Bit 12: Input scaling
Bit 13: Output scaling
Bit 14: Span exceeded
Bit 15: Urcal.Error
Bit 16: Transducer error
2020* 1 I/O status unsigned8 ro Bits 0..3: Inputs 1...4
Bits 4...7:Outputs 1...4
