Example 3:
The intention is to set up the tare value as 23.250 kg (transfer as a long value,
i.e. 23.250 =23250).
Assumed settings: unit ”kg”; decimal places: 3
Protocol on the amplifier:
Identifier 1st byte 2nd byte 3rd byte 4th
byte
5th byte 6th byte 7th
byte
8th
byte
0603 23 80 21 01 D2 5A 00 00
CAN
identifier
Write 4
bytes
Index
low byte
Index
high byte
Subin
dex
Low byte
23.250 kg=23500(=5AD2Hex)
High
byte
Response from amplifier:
Identifier 1st byte 2nd byte 3rd byte 4th byte 5th byte 6th
byte
7th
byte
8th
byte
0583 60 80 21 01 X X X X
CAN
identifier
Write
acknowle
dge
Index low
byte
Index
high byte
Subindex don’t care
