CH_STATUS_EXTENDED
Used to inquiry preselected channel value
command not applicable
inquiry CH_STATUS_EXTENDED= ?
response OK, CH_STATUS_EXTENDED\r\n
OK,output_voltage,output_in_EnUnit,overload\r\n
OK,min_voltage, max_voltage, min_En_Unit, max_En_Unit\r\n
OK,switch1_state, switch2_state\r\n
OK,value,channel\r\n
OK, reset_state, easyteach_state, digital_input_state\r\n
OK, output1_state,output2_state\r\n
OK, active_packet_set\r\n
parameters:
output_voltage float Output value of charge amplifier in V
output_in_EnUnit float Output value of charge amplifier in En_Unit
overload int 0.. channels was not overloaded from last
reset. Default after reset of channel. 1..
channel was overloaded and charge
information is lost.
min_voltage float Minimum output voltage.
max_voltage float Maximum output voltage.
min_En_Unit float Minimum output value in En Unit.
max_En_Unit float Maximum output value in En Unit.
switch1_state int State of limit switch 1.
switch2_state int State of limit switch 2.
value int 0 .. channel is in reset (its output value is 0 or
equal offset voltage) 1 .. channel is
operational
ch1 int Always 1.
reset_state int Logical state of reset button input 0..button
not pressed 1..button pressed
easyteach_state int Logical state of easy teach button input
0..button not pressed 1..button pressed
digital_input_state int Logical state of digital input 0..button not
pressed 1..button pressed
output1_state int Logical state of digital output 1.
output2_state int Logical state of digital output 2.
active_packet_set int 1..active packet set 1 2..active packet set 2
help CH_STATUS_EXTENDED?
response OK, CH_STATUS_EXTENDED extended data
