AUTOSCALE_ALLOW (Autoscale = SensorTeach)
Enable/disable auto scale function.
command AUTOSCALE _ALLOW enable
parameters:
enable int 0.. Disable auto scale function 1.. Enable auto
scale function
response OK, AUTOSCALE _ALLOW = enable
parameters:
enable int See description above
inquiry AUTOSCALE _ALLOW = ?
response AUTOSCALE _ALLOW = enable
parameters:
enable int See description above.
help AUTOSCALE _ALLOW?
response OK, AUTOSCALE _ALLOW enable (0..disable, 1.. enable)
CH_AUTOSCALE (Autoscale = SensorTeach)
Auto scale steps for preselected channel.
command CH_AUTOSCALE step
parameters:
step int 0…abort auto scale procedure
1… start auto scale(channel gain is set to
600nC)
2… if loaded charge between 60nC and 600nC
is auto scale procedure completed. Otherwise
is channel gain set to 60nC.
3… if loaded charge between 6nC and 60nC is
auto scale procedure completed. Otherwise is
channel gain set to 6nC.
4… if loaded charge between 500pC and 6nC
is auto scale procedure completed. Otherwise
is channel gain set to 500pC
5…end auto scale procedure
response OK, CH_ AUTOSCALE = step
parameters:
step int 0…auto scale procedure is aborted or auto
scale procedure is completed 1…start auto
scale(channel gain is set to 600nC) 2...
channel gain is set to 60nC. 3...channel gain is
set to 6nC. 4....channel gain is set to 500pC.
5....end of auto scale procedu
inquiry CH_ AUTOSCALE = ?
