HBOT 3D F300 - Device Description and Specifications; Essential Components Overview

Drukarka 3D
Model: HBOT 3D F300
S/N: XXX/YYYY/123456
Rok produkcji | Production year: YYYY
ly voltage: 100-240V ~ 500W 50-60Hz
zy 230V | Nominal current at 230V: In = 2.0A
Spełniane normy / Complaints with: EN 61000-6-3:2007, EN 61000-6-1:2007
3D Printers sp. z o.o.
Aleja Ludomira Różyckiego 1C/4
51-608 Wrocław
www.HBOT3D.com
Top door
Stand-by button
Front door
Chamber fan
air intlet
Filament holder
Leveling feet
USB socket
SD Card slot
Build platform
Chamber fan
air outlet
Touch
Control Panel
Print head
Lead screw
Bowden tube
entry
Guide
rods
Power
switch
Nameplate
Power cord
connection
3. Device Description
7
Before operating the device be sure to familiarize yourself with all device parts. Your failure to familiarize yourself with their locations
and functions may result in misoperation of the device and/or its damage due to user’s fault.
3.1 ESSENTIAL COMPONENTS
3. Device Description
