To switch from one gear to another, at mid stroke press the ,,brake/clutch“ pedal and move the
lever to the required position .
CAUTION: only engage the reverse gear when the machine is stoped.
CAUTION: before engaging the reverse gear, disengage blade rotation.
BLADE DECK UP / DOWN LEVER
FIG. 21A
Lifts or lowers the blade deck and thereby adjust the grass cutting height. Squeeze adjuster lever
toward the wheel, moving up or down to selected lift height.
BLADE ROTATION ENGAGEMENT LEVER
FIG. 22A
Starts or stops rotation
blade disengaged
If lever is engaged without observing safety conditions, the engine switches off if it is running or
else cannot be started.
A brake is simultaneously activated which stops their rotation within a few seconds.
KEY IGNITION SWITCH
FIG. 23A
This key operated control has three positions:
"START" - connects the starter motor
"ON" - activates all parts
"STOP" - everything is switched off
If you release the key on «START», it will automatically return to «ON.
THROTTLE LEVER
FIG. 24A
This regulates the engine‘s r.p.m. The positions are indicated on a plate showing the following
symbols:
"I-I" - CHOKE - cold starting
"I/I" - SLOW - for minimum engine speed
"-" - FAST - for maximum engine speed
• The «CHOKE» position enriches the mixture so must only be used for the time necessary when
starting from cold.
• When moving from one area to another, put the lever in a position between «SLOW» and
«FAST».
• When cutting, shift into «FAST».
