HEIDELBERG Nexscan F 4100 User Manual

Service and Maintenance
Nexscan F 4100/F 4200 – Operation 6–5
ABC
Lamp Change for Transparency Scanning
1. Switch off the device.
Warning:
Pull out the power plug.
The ends of the fluorescent lamps can heat up to
100 °C when switched on.
2. Open the scanner lid.
3. Loosen both knurled screws in the cover.
4. Carefully fold the plate with the glass
pane downwards.
5. Remove the two slotted screws for the
black reflection profile of the fluorescent
lamps. Remove the reflection profile. The
fluorescent lamps are now accessible.
3
