Mounting Originals 5
TANGO / TANGO XL – Operation 5–15
■ Perform the rest of the mounting proce-
dure as already described for the various
original sizes.
0 Aligning the Original according to a
Prescribed Angle
If you wish to mount your original accord-
ing to a prescribed angle (e.g. for an adver-
tising insert), proceed as follows:
■ Draw one or more lines of the desired
angle on a film relative to the upper film
edge.
■ Place (and possibly affix) the film onto the
table of the TANGOMOUNT/TANGO-
MOUNT XL and align it relative to the
gridlines or to an edge of the table until
the upper foil edge contacts the drum.
■ Align the original according to one of
these lines on the film, and stick the
upper edge of the original onto the drum.
■ Perform the rest of the mounting proce-
dure as already described for the various
original sizes.
Film
