Technical Data and Accessories 7
TANGO / TANGO XL – Operation 7–3
8 Technical Data
Scanning type Multiplier scanning
Unsharp masking (USM) digital (program-controlled)
Focus computer controlled
Max. scanning speed 30 revolutions/sec. (TANGO)
22 revolutions/sec. (TANGO XL)
Max. useful format 480 x 450 mm (TANGO)
500 x 645 mm (TANGO XL)
Scale range 20 - 3000 % (TANGO)
20 - 1700 % (TANGO XL)
Max. original thickness 2.0 mm
Standard interface SCSI (image data and communications)
SCSI address 5 (preset)
Dimensions
(width x height x depth)
622 x 1536 x 627 mm,
2156 mm height with the drum cover open
Power supply 100 - 230 V ± 10 % single-phase
Frequency 47 - 63 Hz
Rated current 3.0 - 6.0 A
Power consumption approx. 500 W
Ambient temperature 18 to 28 °C
Humidity 30 - 80 % (non-condensing)
Operating weight approx. 250 kg
Noise emission less than 55 dB (A)
