Heidolph Hei-FLOW Value 01 - Digital Interface Commands

Operation Operation
24 25
Digital interface commands
Query
to pump
1)
Feedback
from pump
Explanation
LEDx?
▪ LED=0000\r\n
▪ LED=0001\r\n
Select parameter: x=0-7
▪ LED off
▪ LED on
LED0?=Volume ml
LED1?=Flow ml/min
LED2?=Tube mm (inner diameter)
LED3?=Speed rpm
LED4?=Rotation
LED5?=Direction of rotation right
LED6?=Direction of rotation left
LED7?=Pause sec/min/h (intermittent pause)
DSP?
DSP=xxx\r\n Display query: show actual value
TAx!
- Select function key: x=1-7
TA1!=Cal (calibrate)
TA2!=Start/Stop (rotation key)
TA3!=Change direction of rotation
TA4!=Max (maximum speed)
TA5!=Up (arrow key)
TA6!=Down (arrow key)
TA7!=Select (select key)
SPx=xxxx!
- Set intermittent pause: x=0;2;3
SP0=0001 - 5999 seconds/10 e.g. 100 milliseconds
SP2=0010 - 0599 minutes
SP3=0010 - 0750 hours
SMM=xxxx!
2)
- Flow ml respectively μl (tube dependent):
xxxx=000.0 - 9999
SDZ=xxxx!
- Set rotation rpm:
xxxx=0000 - 9999 (min/max gear dependent)
SDM=xxxx!
2)
- Volume dosing ml e.g. μl (tube dependent):
xxxx=000.1 - 9999 (not allowed for calibrating)
SSD=xxxx!
2)
- Set inner tube Ø : x=4digit gure
xxxx=0000 (see following section
“Interface commands: set tube”)
-
OK\r\n Command successful
-
ERROR\r\n Command failed
-
PO/r/n Dosing completed
1)
Interface parameter RS 232: 9600 Baud, No Parity, 8 Bit, 1 Stopbit
2)
Also see chapter „Technical data, Table tube selection” for tube dependent parameters
▪ Do not send commands as package,
minimum pause 0.1 seconds
▪ xxxx substitutes a 1 - 4 digit gure
Interface commands: set tube
Command Inner tube Ø
SSD=0000! 0.8 mm
SSD=0001! 1.0 mm
SSD=0002! 1.7 mm
SSD=0003! 2.0 mm
SSD=0004! 3.0 mm
SSD=0005! 3.1 mm
SSD=0006! 4.0 mm
SSD=0007! 4.8 mm
SSD=0008! 5.0 mm
SSD=0009! 6.0 mm
SSD=0010! 6.3 mm
SSD=0011! 7.0 mm
SSD=0012! 7.9 mm
SSD=0013! 8.0 mm
SSD=0014! 9.0 mm
