Table tubes
Flow rates are guidelines and pertain to Tygon® (standard) tube, media water.
Single-channel pumps Wall thickness 1,6 mm
Ø inner (mm) 0.8 1.7 3.1 4.8 6.4
Ø outer (mm) 4 4.9 6.3 8 9.5
Pressure max. continuous (bar) 0.7 0.5
Pressure max. short time (bar) 1.7 1.5
Suction height (mWs) 8.8 8.8 6.7
Pump head Pump Flow rate H
2
O (ml/min)
SP standard
SP vario
(Pu 2)
Hei-FLOW Value 01 - 5-61 19-223 44-519 75-861
Hei-FLOW Advantage 01,
Hei-FLOW Precision 01
- 2-55 9-221 21-530 33-813
Hei-FLOW Value 06 - 22-249 93-1,037 228-2,613 364-4,151
Hei-FLOW Advantage 06,
Hei-FLOW Precision 06
- 11-257 43-1,017 105-2,549 167-4,056
SP quick
(Pu 1)
Hei-FLOW Value 01 0.83-9 3-41 11-134 25-292 36-413
Hei-FLOW Advantage 01,
Hei-FLOW Precision 01
0.38-9 2-40 5-126 12-233 17-409
Hei-FLOW Value 06 4-35 17-197 57-695 123-1,494 186-1,765
Hei-FLOW Advantage 06,
Hei-FLOW Precision 06
2-33 8-186 26-653 59-1,529 89-2,072
Single-channel pumps Wall thickness 2,5 mm
Ø inner (mm)
4.8 6.4 7.9
Ø outer (mm)
9.8 11.3 12.9
Pressure max. continuous (bar)
0.8
Pressure max. short time (bar)
1.8
Suction height (mWs)
8.8
Pump head Pump
Flow rate H
2
O (ml/min)
SP standard
SP vario
(Pu 2)
Hei-FLOW Value 01
42-493 68-773
-
Hei-FLOW Advantage 01,
Hei-FLOW Precision 01
15-491 28-769
-
Hei-FLOW Value 06
203-2,426 313-3,782
-
Hei-FLOW Advantage 06,
Hei-FLOW Precision 06
92-2,390 139-3,821
-
SP quick
(Pu 1)
Hei-FLOW Value 01
26-299 38-454 50-636
Hei-FLOW Advantage 01,
Hei-FLOW Precision 01
12-299 18-435 25-630
Hei-FLOW Value 06
123-1,580 180-2,411 257-3,436
Hei-FLOW Advantage 06,
Hei-FLOW Precision 06
58-1,527 85-2,248 113-3,171
Multi-channel pumps Wall thickness 0.9
Ø inner (mm) 0.25 0.51 0.89 1.42 2.79
Ø outer (mm) 2.05 2.31 2.69 3.22 4.59
Pressure max. continuous (bar) 0.5
Pressure max. short time (bar) 1.5
Suction height (mWs) 7
Pump Pump head Cassette Flow rate H
2
O (ml/min)
Hei-FLOW
Value 01
C 4:
(Pu 9)
small: max.
4 Cassettes
0.04-0.53 0.17-2 0.57-6 1-15 4-37
C 12:
(Pu 8)
small: max.
12 Cassettes
0.005-0.11 0.02-0.42 0.10-1 0.23-3 0.69-8
Hei-FLOW
Advantage 01,
Hei-FLOW
Precision 01
C 4:
(Pu 9)
small: max.
4 Cassettes
0.02-0.49 0.08-2 0.24-6 0.60-14 2-36
C 12:
(Pu 8)
small: max.
12 Cassettes
0.005-0.11 0.01-0.54 0.03-1 0.10-3 0.29-9
Multi-channel pumps Wall thickness 1.6
Ø inner (mm) 0.8 1.7 3.1 4.8 6.4
Ø outer (mm) 4 4.9 6.3 8 9.5
Pressure max. continuous (bar) 0.7 0.7 0.5
Pressure max. short time (bar) 1.7 1.7 1.5
Suction height (mWs) 7 7 6.7
Pump Pump head Cassette Flow rate H
2
O (ml/min)
Hei-FLOW
Value 01
C 8:
(Pu 0)
medium: max.
8 Cassettes
0.55-6.97 2.17-27 - - -
large: max.
4 Cassettes
- 2-27 7-85 18-246 26-364
Hei-FLOW
Advantage 01,
Hei-FLOW
Precision 01
C 8:
(Pu 0)
medium: max.
8 Cassettes
0.24-7 1-26 - - -
large: max.
4 Cassettes
- 1-27 4-90 8-192 11-329
For high dosing accuracy choose a tube with small inner diameter.
For fast dispensing choose a tube with large inner diameter.
Flow rate depends on tube material, dispensed media and tempera-
ture. Flow rate can therefore vary and may deviate signicantly from
indicated values.
