Henkelman Jumbo Plus - 2.1. Description of the packaging process; machine functions

USER MANUAL
11
Jumbo Version: JUM-EN-UL-0 23-03-15
NO.
PART
DESCRIPTION
SECTION
4
Controlpanel
 See section
2.5
5
Machine housing
 The machine frame contains all necessary parts for
the correct functioning of the machine
6
Vacuum pump
 See section
2.3
7
Power connection
 See section
2.4
2.1. Description of the packaging process / machine functions
FUNTION
 This chapter provides an overview of the process and the available machine
functions
 In chapter 5.5 you will find information on how to set the parameters to the correct
values
2.1.1. The packaging process / machine functions
The following steps are taken during the process. For the detailed procedure, see Chapter 0
STEP
PROCESS PHASE
OPERATION
1
Preparations
 The operator puts the product in a vacuum bag and
places it on the work top with the opening on the
seal bar
2
Extracting Vacuum
 The vacuum process is started by closing the lid
 During the cycle, the air will be removed from the
chamber until the set time has been reached
3
Sealing
 The seal bars are pressed against the contra bars,
with the vacuum bag in between and melt the bag
to be closed
 During the sealing, the material of the vacuum bag
is heated and compressed to form a hermetic
sealing. The function is programmed in seconds
 As an option, a cutting wire is available. The
purpose of this wire is to remove the remaining foil
from the excess flap
4
Releasing vacuum
 The vacuum is released, by letting air back into the
chamber
