6.7. Replacing the silicone rubber on the silicone holders
EXPLANATION
 In order to obtain a seal of good quality, the rubber should not be damaged and
the surface must be flat
 Damage may be caused by burning with the seal wire or mechanical contact
 Replace the silicone rubber if it is damaged, or in accordance with the
maintenance diagram in chapter 6.1
Figure 14: Replacing the silicone rubber of the silicone holders
NO.
WHAT TO DO
ACTION
RESULT
1
Remove the old
silicone rubber
 You can pull the old silicone rubber
(Figure 14:1) from the holder
2
Cut the new silicone
rubber
 Cut a new piece of rubber. Make sure that
it is just as long as the holder
 The size is very important, it will cause
problems with the seal of the bag if the
rubber is too short or too long
3
Place the new silicone
rubber
 Place the new piece in the silicone holder
by pushing it into the recess
 Ensure that the silicone rubber is fully and
uniformly placed in the slot. It is also
important that the surface of the silicone
rubber is smooth after it is in place and
that it shows no signs of stress
