2.4. Electrical installation
FUNCTION
 The electrical installation provides power to the vacuum pump, sealing system
and control unit
 See the electrical diagram for the further structure and operation of the electrical
installation. For the electrical diagram, please contact your dealer
ATTENTION!
 Work on the electrical installation may only be carried out by a technical expert
 When performing maintenance on the machine, always unplug the power cable
to avoid electrical shock
 The machine should always be connected to a proper grounded outlet
Figure 4: Overview of the electrical installation
The machine consists of the following components
NO.
PART
DESCRIPTION
SECTION/
LOCATION
1
Power cable
 To connect the power supply to the machine
2
Control panel
 The available control functions can be used
 Your machine has the following control type:
o Single Program Digital Control (SPDC)
2.5
2
1
