6.6. Replacing the sealing wire
EXPLANATION
 Depending on your machine specification you can have one of the following
(combinations of) seal elements:
• Double seal: Two sealing wires
• Cut-off seal: One sealing wire and one cutting wire
• Wide sealing: One wide sealing wire
 The process of replacing of the seal elements is the same for all types
 Replace the sealing wires if the wire and/or the Teflon tape is damaged, or in
accordance with the maintenance diagram
Figure 12: Removing the seal bar
Figure 13: Replacing the sealing wire
6
5
4
3
2
1
1
