ICONS
Some icons and warnings are included on the machine among others to indicate the possible risks
involved to the users.
ICON
DESCRIPTION
LOCATION
Nameplate
At the rear of the machine
Warning sign "HIGH VOLTAGE"
At the rear of the machine
Warning sign “SHOCK RISK”
At the rear of the machine
Warning sign "HEAT"
On the housing of the machine
Warning sign "HEAT"
 On the sealbar(s)
 On the vacuum pump
CAUTION!
Regularly check that the icons and markings are still clearly recognizable and
legible. Replace them if this is no longer the case
