Henkelman Jumbo Plus - Page 36

36
USER MANUAL
Jumbo Version: JUM-EN-UL-0 23-03-15
NO.
WHAT TO DO
ACTION
RESULT
1
Remove the seal bar
from his holders
 Lift the sealing bar (Figure 12:1) from the
cylinders
2
Remove the teflon
tape
 Remove the teflon tape (Figure 13:1) that
protects the sealing wires
3
Remove the old
sealing wires
 Remove the screws (Figure 13:2) on the
bottom side of the seal bar, and remove
the sealing wires (Figure 13:3)
4
Replace the teflon
tape on the sealing
bar
 Pull the teflon tape from the top of the
sealing bar (Figure 13:4)
 Clean the bar with a lint-free cloth
 Put a new piece of Teflon tape of the
same length on the sealing bar
5
Replace the sealing
wires
 Cut a new piece of sealing wire or cutting
wire at the length of the seal bar plus
about 15 cm (6 inches)
 First place the wire on one side of the seal
bar by tightening the screws (Figure 13:2)
 Place the other end of the wire in a
straight line and tighten with pliers. Then
fasten it by tightening the screws
 Trim the ends of the wire on both sides
6
Replace the teflon
tape on the sealing
wire
 Cut a piece of teflon tape at the length of
the seal bar plus about 5 cm (2 inches)
 Stick the tape smoothly and without folds
over the sealing wires on the sealing bar
7
Place seal bar
 Place back the seal bar
