Add oil
NO.
WHAT TO DO
ACTION
RESULT
1
Add oil
 Remove the oil filler plug (Figure 3:5)
 Add oil until the oil level is between the
"max" and "min" level (Figure 3:3)
 Place back the oil filler plug
Replacing oil
NO.
WHAT TO DO
ACTION
RESULT
1
Change oil
 Place a drip pan under the oil drain plug
(Figure 3:4)
 Remove the oil drain plug (Figure 3:4)
 Place back the oil drain plug
The oil drains from the
pump
2
Fill with new oil
 Remove the oil filler plug (Figure 3:5)
 Add oil until the oil level is between the
"max" and "min" level (Figure 3:3)
 Place back the oil filler plug
