14. Interface Description
Urispec
®
Plus may be connected to a computer via the RS232 or the USB-
interface (Pic. 4) (work station or laboratory information system).
14.1. Serial Interface
Protocol RS232, 19200 Baud, 8 bit, no parity
Connection plug arrangement:
PIN Signal Description Direction
1 Nc Not wired
2 RxD Data reception Input
3 TxD Send Output
4 Nc Not wired
5 GND Signal ground --
6 Nc Not wired
7 Nc Not wired
8 Nc Not wired
9 Nc Not wired
14.2. USB 1.1-Interface
USB-jack Type B (Pic. 4
E
). The instrument will be identied as a serial inter-
face.
14.3. Transmission Protocol
The data is released via the interfaces as plain text. The received dataset cor-
responds to the format of the printout.
14.4. Barcode Scanner, PC-Keyboard
A USB-jack Type A (Pic. 4
F
) is provided for connection of a keyboard or bar
code scanner.
14.5. Ethernet-Interface
The RJ45 jack (Pic. 4
I
) is not supported.
