S18F11: Write data (host -> reading device, reply)
This message is used for writing the MID on the antenna head specified in the TARGETID.
S18F11,W
<TARGETID>
<MID>
The reading device must be in maintenance mode to write the MID
with the Message S18F11.
If the reading device is not in maintenance mode, the execution is
cancelled and acknowledged with SSACK = „EE“ equipment error.
S18F12: Write Data, Acknowledgment (reading device -> host)
This message indicates whether the process for writing the MID on the subsystem specified in
the TAR- GETID was successful or failed.
S18F12
<L,4
>
<TARGETID>
<SSACK>
< L,1
<STATUSLISTE>
>
The reading device can be in maintenance mode (MT) to write the MID with the message
S18F11.
