10.5 Parameter
The parameters 0, 1, 2 and 7 are only valid if the reader is equipped
with a corresponding I / O module and provides one input per antenna
port.
*): Since software revision V1.5 some parameters are implemented
for each antenna port. Addressing of the parameter takes place via
the reader ID of the message. In this realisation, the parameter is
present once per antenna port. If no parameter arrays should be
used, please ask the manufacturer (parameter 63)!
The data element „Parameter No.“ can have the following values. List of public paramters:
Delay time for the presence sensor.
01 .. 99 (0,1 Sekunden)
Default: 10 … (1 second)
Realisation: a separate parameter for each port *)
Read mode for reading automatically started by external
input. 00 - read only one page
01 - read until the end character or empty
character2) 02 - read all pages
10 - read only one page with previous sensor Check1)
11 - read until the end character / empty character
with previous sensor check 1) 2)
12 - read all pages with previous sensor
Check1) 99 - Disable sensor
1) If the Sensor Check (first byte = 1) is activated, the assignment of
the potential-free input is checked before initiating a read / write
process. When used, the read / write process is started, otherwise the
error message „NOTAG“ is sent.
2) ‚E‘ or ‚F‘ in ID bits 0...3 of the read ID
Default: 00 … (read only one page)
Realisation: a separate parameter for each port *)
Page for readmode „00“.
01 First page of each transponder
02.. 17 Side of a multipage
transponder Default: 01 (read first
page)
Realisation: a separate parameter for each port *)
Time between two read / write attempts.
01 .. 99 (0,1 s)
Default: 05 … (0,5 seconds)
Realisation: a separate parameter for each port *)
