6.4.4 Test mode sticker
The device label is located on the reading unit housing.
By setting the DIP-switch 3 the test mode is activated.
The test mode read or write is set with the DIP switch 4.
The selection oft he antenna port is changed by the DIP
switched 1 and 2.
Further functions see section DIP switch.
3 off: Start Antenna Tuning
3 on: Off-Read / On-Write
Testmode on/off
2 3 4
off on on
on off on
1
2
3
4
DIP Switches
DIP /Ant Port: 1
