7.8 RS232 connection
The serial interface is implemented as a Sub-D plug connector (9-pin). A serial connection
line (1:1 circuit) can be used.
PIN
Signal
1
NC
(Optional GND)
2
TxD
3
RxD
4
NC
5
GND
6
NC
7
NC
8
NC
9
NC
(Optional +5V)
