11.4 Parameter
*): Since software revision V1.5 some parameters are implemented
for each antenna port (parameter array). Addressing of the
parameter takes place via the reader ID of the message. In this
realisation, the parameter is present once per antenna port.
If no parameter arrays should be used, please ask the manufacturer
(parameter 63)!
**): Since software revision V1.5, the reader is always started with the
default baud rate 19200Bd because of the protocol recognition.
Please ask manufacturer HERMOS if other baud rate is required!
Nr.
(DEZ)
Nr.
(HEX)
Parameter name
Description
0
0x00
Gateway ID
The gateway ID is part of the device ID. The reading
unit simultaneously acts as gateway and reader (CID-
RW with integrated read head). It corresponds to the
„Lower Device-ID“ in the message header.
00 .. 255
Default: Low Byte of serial number
1
0x01
Baud rate
Data transmission rate of the RS232 interface
Default: 192 19200 Baud **)
2
0x02
Inter-character Timeout T1
1 … 100 1/10 s
Default : (5) 0,5 s
3
0x03
Block protocol Timeout T2
1 … 250 1/10 s
Default : (30) 3 s
4
0x04
Reply Timeout T3
1 … 120 1 s
Default : (10) 10 s
5
0x05
Inter-block Timeout T4
1 … 120 1 s
Default : (45) 45 s
6
0x06
Retry limit RTY
Number of retry attempts for a question or message.
Default : 3
9
0x09
Heartbeat time
The reader sends a S1F1 message to the host at
specified intervals.
0 … no heartbeat
1 … 255 1 s (1-255s)
Default : 0 … no Heartbeat
11
0x0B
ReaderID
The reader ID is part of the device ID. The reader ID
corresponds to the 7 LSB (least significant bits) of the
„Upper Device ID“ in the message header.
00 … 127 (0x00 – 0x7F)
Default : 0x01
