11.2 Directory Data Elements
This section defines the data elements used in the standard SECS-II messages described
in the message details section.
Syntax:
Name A unique name for this data item. This name is used in the message definitions
.
Format A unique name for this data item. This name is used in the message
definitions. The allowed element format code that can be used for this
default data element. Element format codes are displayed in
hexadecimal and octal, as described in chapter Data element.
The notification „3 ()“ indicates a signed integer format (30, 31, 32, 34).
Description A description of the data element with the meaning of each value. Where used
standard messages in which the data element occurs.
Verification code
0
...
Sensor 0 was the Initiator
1
...
error, not accepted
Verification code
0
...
No error
1
...
error, not accepted
The value of the alarm state refers to the last read. If a read or write error occurs, the alarm state
is activated. A successful read or write deactivates the alarm state. When leaving the
maintenance mode, the alarm state is also deactivated.
0
...
No error
1
...
error, not accepted
Alarm-Codebyte
Only the occurrence of an error is reported. Errors are usually not reset.
Bit 8 = 1 Alarm activated
Where used S5F1
ACKC3 Format: B[1]
ACKC5 Format: B[1]
ALARM STATE Format: A[1]
ALCD Format: B[1]
