OFLACK Format: B[1]
MIDRA Format: B[1]
Material ID verification code
0 Material ID confirmed; the presence sensor was the initiator
1 Not specified
2 Material ID confirmed - reaction to externally triggered process; the message can not be assigned
to a sensor
>2 Material ID not confirmed
The initiator can be taken from the data element PTN.
Where used S3F14
Material ID verification code
2 confirmation, MID will be sent later in S3F13
Where used S3F12
Confirmation code for OFFLINE request.
0 ONLINE accepted (reader is online)
Where used S1F16
Confirmation code for ONLINE request.
0 ONLINE accepted (reader is online)
Where used S1F18
The data element corresponds to the transponder data. It contains the transponder page and the data
content of the page.
PAGEDATA [0] Correspond to the page number. The value of the page number is displayed in
the data element „DATASEG“.
PAGEDATA [1-8] The 8 bytes (one page) of the transponder ID follow.
Where used S3F7, S3F13
MIDAC Format: B[1]
ONLACK Format: B[1]
PAGEDATA Format: B[9]
