Appendix . Servo system application
-4
I.2. Example of other application
A. Rotary table
- Prepare the motion program in the host controller.
- Enter the operating signal and operate the angle.
- After angle operation, position decision completion signal(INPOS) is sent out externally.
B. Roll feeder
- Set the feed to the work.
- Operate the position according to the feed start signal input from the press.
- By using the position decision completion signal, execute the press work.
( The position decision completion signal and feed start signal can be interlocked on the sequence.)
