1. Model check and handling
1-24
1.5. Installation
1.5.1. Installation of servo drive
1) Operating environment
0-50 (There should be no freezing) Note)
90% RH or lower (There should be no vapor)
Note) Inside control panel temperature specifications : To ensure maximum operating
life and reliability of the drive, maintain the average control panel temperature at
40 or lower.
2) Installation direction and intervals
- Install FDA7000 can be seen from the front.
- If the drives are installed in a closed control panel, maintain an interval of more than 10
mm between drives and more than 40 mm between top and bottom. If multiple number of
control panels are installed in parallel, about 100 mm space is required on the upper side.
In case of installing fans, avoid heat.
- Regenerative resistor, heating source, away from the drive.
3) Prevention of ingress of dust
- Exercise caution when drilling control panels to prevent chips produced by drilling from
getting into the drive.
- Take appropriate measures to prevent oils, water and metal powder from getting into the
drive from openings in the control panels and the fan installed on the ceiling.
- If the drive is used in a place with large amount of toxic gases and dust, protect the drive
with an air purge.
1.5.2. Servo motor installation
1) Operating environment
0-40 (There should be no freezing)
80% RH or lower (There should be no vapor)
2) Caution when assembling load system (Prevent impact on shaft)
To Next Page
