Higen FDA7002EX User Manual

3. Parameter setting
3-2
3.1. Status display parameter[StE-]
StE-01
Display Select
Unit
-
Setting range
100~ 1330
Manufactured
default
1203
Speed/Torque/
Position control
When the power of the servo drive is turned on, this sets the menu to display on the display
window. The first and second space indicates the upper menu number of each menu, and third
and fourth space indicates the lower menu number. For example, if it is set as StE-01 = 1203, the
“12” means the StE menu and “03 refers to the StE-03.
[ First and second space value ]
Upper
menu
name
P01
P02
P03
P04
P05
P06
P07
P08
P09
JOG
ALS
StE
1
st
and 2
nd
value
01
02
03
04
05
06
07
08
09
10
11
12
Refer to each parameter for the third and fourth menu number.
StE-02
Command Speed
Unit
rpm
Setting range
-9999.9 ~ 9999.9
Manufactured
default
-
Speed/position
control
StE-03
Motor Speed
Unit
rpm
Setting range
-9999.9 ~ 9999.9
Manufactured
default
-
Speed/Torque/
Position control
StE-04
CCW Speed Limit
Unit
rpm
Setting range
0.0 ~ 9999.9
Manufactured
default
-
Speed/Torque/
Position control
StE-05
CW Speed Limit
Unit
rpm
Setting range
-9999.9 ~ 0.0
Manufactured
default
-
Speed/Torque/
Position control
StE-06
Command Pulse
Unit
pulse
Setting range
-99999 ~ 99999
Manufactured
default
-
Position control
StE-07
Feedback Pulse
Unit
pulse
Setting range
-99999 ~ 99999
Manufactured
default
-
Position control
StE-08
Error Pulse
Unit
pulse
Setting range
-99999 ~ 99999
Manufactured
default
-
Position control
StE-09
Command Torque
Unit
%
Setting range
-300.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
StE-10
Load Rate
Unit
%
Setting range
-300.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
StE-11
Max Load Rate
Unit
%
Setting range
-300.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
