1. Model check and handling
1-25
It is important to accurately match the motor shaft with the shaft center of the connecting
machine. Mismatched shaft center causes vibration, and may cause damage to the bearing.
Use a rubber hammer to install couplings to prevent excessive force from being applied to the
shaft and bearing.
Check 4 places in turn. The difference between maximum and minimum should be 0.03 or
lower.
3) Load tolerance on shaft
- Use flexible couplings, and maintain the shaft center deviations within the specified
tolerance.
- Use pulleys and sprockets with the allowable load.
-
MOTOR MODEL
RADIAL LOAD
AXIAL LOAD
REFERENCE DIAGRAM
Series
Type
N
Kgf
N
kgf
CN
CN01~CN05
EX02
196
20
68
7
Radial
Load
Axial
Load
CN06~CN08
EC06~EC08
245
25
98
10
CN09~CN15
490
50
196
20
CN20~CN30
EC22~EC40
686
70
343
35
CN30A~CN50A
1470
150
490
50
KN
KN03~KN07
EK05~EK06
245
25
98
10
KF08~KN11
490
50
196
20
KF15~KN22
EK16
686
70
343
35
KN22A~KN55
EK30
1470
150
490
50
TN
TN05~TN09
490
50
196
20
TN13~TN17
ET12
686
70
343
35
TN20~TN75
ET20
1470
150
490
50
LN
LN03~LN06
490
50
196
20
LN09~LN12
686
70
343
35
LN12A~LN40
1470
150
490
50
KF
KF08~KF10
490
50
196
20
KF15
686
70
343
35
KF22~KF50
1470
150
490
50
