1. Model check and handling
1-32
<Note 1>
0~ +50 (Where not to freeze)
(In-cabinet temperature specification below + 40 ° C)
90RH or below (No condensation)
Indoors
(no corrosive gas, flammable gas, oil mitt, dust free place)
1000m or less above sea level / Within X, Y, Z axis 2.0G
(2) Wiring
•Use wires that meet the specifications. The servo motor may not work.
•Do not install a phase advance capacitor, surge absorber, or radio noise filter on the servo
drive output side.
•Connect the output side (terminal U, V, W, FG) correctly.
The motor may malfunction.
•When attaching the DC relay for control output signal to the control output signal, pay
attention to the direction of the surge absorption diode. The signal cannot be output due to a
fault, and the protection circuit does not operate during an emergency stop. Refer to the
instruction manual for the diode direction.
(3) Commissioning and Adjustment
•Check and adjust each parameter before operation. Unexpected movements may occur
depending on the machine.
