Higen FDA7002EX User Manual

2. Wiring and connection
2-9
AC SERVO
operating
device
FDA7015/
FDA7015B
FDA7020/
FDA7020B
FDA7030/
FDA7030B
FDA7045
FDA7075
FDA7110
FDA7150
Wire
thickness
AWG #12
(3.5mm
2
)
AWG #10
(5.5mm
2
)
AWG #8
(8mm
2
)
AWG #6
(14mm
2
)
AWG #4
(22mm
2
)
Open/close
device
GMC-40(35A)
GMC-50(50A)
GMC-85(80A)
GMC-100(100A)
Breaker
ABS33b
(10A)
ABS33b
(20A)
ABS33b(30A)
ABS53b
(50A)
ABS63b
(60A)
ABS103b(100A)
Noise filter
NFZ-4030SG(30A)
NFZ4040
SG(40A)
FT3RE-4060
(60A)
FT3RE-4080
(80A)
External
regenerated
resistance
250W 25
(Drawing A)
250W 25 parallel 2 units
(Drawing A)
250W 25Ω
parallel 4
units
(Drawing B)
800W 8Ω
parallel 2
units
(Drawing C)
1kW 6Ω
parallel 2 units
(Drawing C)
♥ Open/close device and Breaker : LS Industrial Systems,
http://www.lsis.biz
♥ NOISE FILTER : Woonyoung(http://woonyoung.com), OKY (
http://www.oky.co.kr
),
ORIENT(
http://www.suntronix.com
)
M4
∮4.3
Length:300
220
239
30
60
<Drawing A>
<Drawing B> Order Code : FDA500010S(1000W/6.25Ω)
