Section 3 - Preparing the Rockpicker
Shut down the tractor and remove
the key before repairing, servicing,
lubricating or cleaning the
machine.
Relieve all hydraulic pressure in
the hoses before going near the
machine.
1. Check the condition of the apron and the
rock bucket.
Do not enter the reel or apron
area while the reel is rotating or
rocks are lodged against the bats.
Contact with the moving pickup
reel or spring loaded bats under
pressure will cause serious injury
or death.
2. Check that the upper and lower bolts on
each tine are tight.
Install the apron locks on both
sides when servicing the
rockpicker. Serious injury from the
apron lowering could result if both
locks are not installed.
- The upper tine bolts have nut
keepers. The tines can be tightened
from the bolt head.
Check Condition of Apron and Bucket
214010
Page 3-2
