Section 6 - Storing the Rockpicker
Remove the Apron Lock - Right Side
216227C
Right Apron Lock in Storage
216235C
Right Lock
- Remove the apron lock (1) on the right
side of the apron.
- Remove the clip pin.
- Remove the lock from the apron.
- Place the right apron lock (1) into the
storage position on the right side of
the frame behind the motor.
- Fasten with the clip pin (2).
Page 6-2
