HIKVISION DS-2CD2432F-I

Installation Manual of Network Camera
100
5. Loosen the focus lever and move the screw between F (Far) and N (Near) to obtain the optimum
focus.
6. Tighten the focus lever.
7. Assemble the camera.
Zoom/Focus Lever
Figure 4-33 Zoom and Focus Adjustment
4.6 Type VI Bullet Camera
4.6.1 Camera Description
The overview of the network bullet camera is shown below:
1
2
3
6
5
4
7
Figure 4-34 Overview
