HIKVISION DS-2CD2432F-I

Installation Manual of Network Camera
93
4). Tighten No.2 adjusting screw.
5). Loosen No.3 adjusting screw to adjust the azimuth angle [0° ~ 360°].
6). Tighten No.3 adjusting screw.
1
2
3
Figure 4-22 3-axis Adjustment
4.5 Type V Bullet Camera
4.5.1 Camera Description
The overview of the network bullet camera is shown below.
5
11
3
8
6
10
9
7
4
1
2
Figure 4-23 Overview
Table 4-5 Overview
