HIKVISION DS-2CD2432F-I

Installation Manual of Network Camera
111
Figure 4-52 Paste the Bracket
3. Install the cylindrical sensor into the mounting hole in the round rail bracket.
4. Turn the locking sleeve to fix the sensor. As shown in Figure 4-53.
Figure 4-53 Install the Cylindrical Sensor
