HIKVISION DS-2CD2432F-I Installation Manual

Installation Manual of Network Camera
44
Figure 3-49 Disassembling
4. Install the dome drive to the back box and pull the cables through the side outlet on the bottom of
the back box.
If you need to pull the cable through the cable outlet from the side of the camera, please remove the
cover and use water-proof joints and water-proof pipe to route the cables.
Side Outlet
Figure 3-50 Side Cable Routing
5. Connecting the network cable and power cable.
