9. Install the inner black liner back to the camera.
10. Align the bubble with the camera.
11. Tighten the screws to secure the bubble with the camera as shown below.
Figure 3-71 Secure the Bubble
Wall Mounting
For the wall mounting, you have to purchase a wall mount.
Steps:
1. Disassemble the camera.
2. Install the wall mount and mounting adapter as shown below.
3. Align the screw holes of the mounting base with the corresponding screw holes of the mounting
adapter.
4. Secure the mounting base to the mounting adapter with four screws.
