User Manual of DS-7200/7300/8100 Series DVR
104
Playback by alarm input search is supported by DS-7224/7232, DS-7300 and DS-8100 models only.
Steps:
1. Enter the playback interface.
Menu>Playback
2. Click and select to enter the Event Playback interface.
3. Select Alarm Input, Motion, Line Crossing Detection or Intrusion Detection as the event type, and
specify the start time and end time for search.
The line crossing detection or intrusion detection search is supported by the Smart HDVR/DVR only.
Figure 6. 6 Video Search by Motion Detection
4. Click Search, and the record files matching the search conditions will be displayed on a list.
5. Select and click button to play back the record files.
You can click Back to return to the search interface.
If there is only one channel triggered, clicking button takes you to Full-screen Playback interface of
this channel.
If several channels are triggered, clicking button takes you to the synch playback interface. Check
checkbox to select one channel for playback or select multiple channels for synchronous playback.
The max. number of channels for synchronous playback supported varies to different models.

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
