User Manual of DS-7200/7300/8100 Series DVR
108
2. Select to enter the Tag Playback interface.
3. Select the channels from the list, and specify the start time and end time for search.
4. Optionally, you can input the keyword of the tag name in the Keyword text field to narrow the search.
5. Click Search, and the tags matching the search conditions will be displayed on a list.
6. Click button to play back the file.
You can click the Back button to back to the search interface.
Pre-play and post-play time can be set according to actual needs.
Pre-play time and post-play time is added to the time point of the tag.
Figure 6. 12 Interface of Playback by Tag
Figure 6. 13 Toolbar of Playback by Tag
Table 6. 1 Detailed Explanation of Playback-by-tag Toolbar
Button
Operation
Button
Operation
Button
Operation
/
Mute/Audio on
/
Start/Stop clipping
Save clip(s)
Add default tag
Add customized tag
Tag management
Digital Zoom
30s backward
/
Pause/Play Reverse
Stop
30s forward
Previous tag
Slow forward
Fast forward
Process bar
Next tag
/
Scaling up/down
time bar
Full Screen
Exit
Video type bar
Tag playback

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
