User Manual of DS-7200/7300/8100 Series DVR
165
5. Configure the following Email settings:
Enable Server Authentication (optional): Check the checkbox to enable the server
authentication feature.
User Name: The user account of sender’s Email for SMTP server authentication.
Password: The password of sender’s Email for SMTP server authentication.
SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com).
SMTP Port: The SMTP port. The default TCP/IP port used for SMTP is 25.
Enable SSL (optional): Click the checkbox to enable SSL if required by the SMTP server.
Sender: The name of sender.
Sender’s Address: The Email address of sender.
Select Receivers: Select the receiver. Up to 3 receivers can be configured.
Receiver: The name of user to be notified.
Receiver’s Address: The Email address of user to be notified.
Enable Attached Pictures: Check the checkbox of Enable Attached Picture if you want to send
email with attached alarm images.
Interval: The interval refers to the time between two actions of sending attached pictures.
Figure 9. 37 Configure Email Settings
6. Click the Apply button to save the Email settings.
7. You can click the Test button to test whether your Email settings work. The corresponding Attention
message box will pop up.
Figure 9. 38 Email Testing Attention
