User Manual of DS-7200/7300/8100 Series DVR
17
Table 1.3 Description of Control Panel Buttons
Receiver for IR remote control.
Connect to USB mouse or USB flash memory devices.
Alarm indicator turns red when a sensor alarm is detected.
Ready indicator is normally blue, indicating that the DVR is functioning properly.
Indicator turns blue when DVR is controlled by an IR remote.
Indicator turns red when controlled by a keyboard and orange when IR remote and
keyboard is used at the same time.
Indicator does not light when the DVR is controlled by the IR remote control with
the address of 255.
HDD indicator blinks in red when data is being read from or written to HDD.
Tx/Rx indictor blinks in blue when network connection is functioning properly.
Indicator turns blue when the device is armed;
Indicator does not light when the device is disarmed;
The arm/disarm state can be initiated by pressing and holding on the ESC button
for more than 3 seconds in live view mode.
Channel Status
LED Indicators
The button lights in blue when the corresponding channel is recording; it is red
when the channel is in network transmission status; it is pink when the channel is
recording and transmitting.
Switch to the corresponding channel in Live View or PTZ Control mode.
Input numbers and characters in Edit mode.
Switch between different channels in All-day Playback mode.
Exit and back to the previous menu.
Arm/disarm the DVR in live view mode.
Enter the Manual Record interface.
Turn audio on/off in Playback mode;
In PTZ control mode, pressing the REC/SHOT button and a Numeric button will
call a PTZ preset.
Enter the Playback menu;
Auto scan in the PTZ Control mode.
In PTZ control mode, the ZOOM+ button is used to zoom in the PTZ camera.
Adjust focus in the PTZ Control mode.
Switch between input methods (upper and lowercase alphabet, symbols and
numeric input).
Edit text fields. When editing text fields, it will also function as a Backspace button
to delete the character in front of the cursor.
On checkbox fields, pressing the button will tick the checkbox.
In PTZ Control mode, the button adjusts the iris of the camera.
In Playback mode, it can be used to generate video clips for backup.
Return to the Main menu (after successful login);
Turn off audible key beeper by pressing and holding the button for 5 seconds;
Start wiper (if applicable) in PTZ Control mode.
The F1/LIGHT button when used in a list field will select all items on the list.
In PTZ Control mode, it will turn on/off PTZ light.
The F2/AUX button is used to cycle through tab pages.
Switch to the control of spot output;
In PTZ Control mode, it can be used to zoom out the PTZ camera.
Switch between single screen and multi-screen mode.
In PTZ Control mode, it is used to adjust the focus in conjunction with the
A/FOCUS+ button.
Enter the PTZ Control mode.
In PTZ Control mode, it is used to close the iris of the PTZ camera.
The DIRECTION buttons are used to navigate between different fields and items
