User Manual of DS-7200/7300/8100 Series DVR
27
9
HDMI
HDMI video output.
10
USB Interface
Connects USB mouse or USB flash memory devices.
11
LAN1/LAN2 Interface
2 RJ45 10M/100M/1000M Ethernet interfaces.
12
eSATA
Connects external SATA HDD, DVD-R/W.
13
Termination Switch
RS-485 termination switch. Up position is not terminated.
Down is terminated with 120Ω resistance.
14
RS-485 Interface
Connector for RS-485 devices. Connect the T+ and T- terminals to the R+
and R- terminals of PTZ receiver respectively.
KB
Connect the D+ and D- terminals to Ta and Tb terminals of the controller.
For cascading devices, the first DVR’s D+ and D- terminals should be
connected with the D+ and D- terminals of the next DVR.
15
Alarm In/Out
Connector for alarm input/output.
16
GND
Ground(needs to be connected when DVR starts up)
17
100~240VAC
100~240VAC power supply.
18
POWER
Switch for turning on/off the device.

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
