User Manual of DS-7200/7300/8100 Series DVR
80
Figure 5. 11 Holiday Settings
6) Click OK to save setting and back to upper level menu.
Task 2: Draw the Schedule
Steps:
1) Click the icon on the right to select a record type. Different recording types are available for
different models.
 The VCA recording type is supported by the Smart DVR/HDVR series only.
 The Alarm, Motion/Alarm and Motion & Alarm recording types are supported by the
DS-7224/7232, DS-7300 and DS-8100 series only.
To enable Motion triggered recording, you must configure the motion detection settings. For
detailed information, refer to Chapter 8.1 and Chapter 8.2.
2) Use the mouse to drag and draw time periods.
Up to 8 periods can be configured for each day.
Figure 5. 12 Draw the Schedule

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
